Function Room Divider Stackable Folding Partition Panel for Movie Room

Basic Info

Model NO.	85 mm collapsible folding partitions
Customized	Customized
Material	Wood
Condition	New
Surface Color	Customzied
Payment	T/T
Package	Wooden Box
Transport	Depends on Client
Type	Office Furniture
Height	Less for 6 Meters
Width	500-1200 mm
Thickness	85mm
MOQ	No MOQ
Application	Office,Conference Room,Hotel Room Divider
Transport Package	Carton Package, MDF Batten on Four Section Sides
Specification	85 mm thickness
Trademark	EBUNGE
Origin	Guangzhou, China
HS Code	94031000
Production Capacity	50000 Square Meters Per Month

Packaging & Delivery

Package size per unit product 130.00cm * 250.00cm * 8.00cm Gross weight per unit product 30.000kg

Product Description

Function room divider stackable folding partition panel for movie room
1.Details 1)Aluminium movable partition wall have interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.2)To ensure aluminium movable partition wall additional friction connection, shall be integrated with magnetic strip.3)Aluminium movable partition wall are easy element adjustment after installation.4)Aluminium movable partition wall rack system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.5)Aluminium movable partition wall surface panel shall be of 9mm or 12mm MDF with acoustic treatment to the required level.

Series	BG65	BG85	BG100
Panel suspension	Top hung only	Top hung only	Top hung only
Track system	Single or twin point	Single or twin point	Single or twin point
Panel thickness	65mm	80mm / 85mm	100mm
Panel height	Up to 4000mm	Up to 6000mm	Up to 18000mm
Max height	4000mm	6000mm	18000mm
Panel width	600-1230mm	600-1230mm	600-1230mm
Frame construction	Aluminum frame	Aluminum frame	Aluminum frame
Face material	9mm	9mm / 12mm	12mm
Fire safety	Optional Class I or O	Optional Class I or O	Optional Class I or O
Vertical profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles	Aluminum anodised with sealing profiles
Retractable seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals	Aluminum black with double rubber seals
Operation of seals	Manual, with supplied operating handle	Manual, with supplied operating handle	Manual, with supplied operating handle
Locking	Optional lock to pass doors	Optional lock to pass doors	Optional lock to pass doors
Pass doors	Single open in panel or double open in two panel	Single open in panel or double open in two panel	Single open in panel or double open in two panel
Sound insulation	20-32dB Rw	28-36dB Rw	32-50dB Rw
Weight	Approx 22-35kg/sq M	Approx 25-40kg/sq M	Approx30-48kg/sq M
Finish Material	Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather, Insulation board, Fireproof board, Wall paper, Vinyl, Painting,etc. (Customized)

2.Finish and Accessories

Different surface use in different areas.Our main surface is MDF with Melamine, it can be used in Classroom, Restaurant and so on, it's easy to maintain. Fabric and PU leather surface are very popular in conference room and hotel banquet hall. In dancing room, clients usually prefer mirror surface. Also we can design surface based on fabric or pu leather with modern printing photos.If clients prefer to paint color on panels, we suggest MDF bare finish, it'salso very welcomed, because it can make wallpaper, painting on site.

Function Room Divider Stackable Folding Partition Panel for Movie Room

3.Installation
The movable partition wall is composed of many single panels. Each panel is equipped with single or two hanging rollers. It depends on the horizontal hanging roller to make the partition panel hanging along the track. The vertical contact points of every single panel are connected by concave and convex positions. The seal rubbers are embedded and panel top and bottom parts are equipped with a retractable mechanism.When closing, the partition can be hidden in a dedicated storage cabinet, which does not affect the overall appearance.

4.About us
Guangdong Bunge Building Material Industrial is a professional company in manufacturing movable partitions. It also artistically designs and carefully does research and development(R&D). The company has adopted the advanced partition technology of the USA, Germany, and Denmark. We have professional staff with more than 10 years of experience in design, production, and installation.
Our product(movable partition)are widely used in the hotel,banquet hall,meeting room,exhibition hall,conference room,International convention center,KTV,upscale restaurants,office building,school,hospital and others.
Nowadays, the modern trend in the building needs more flexibility and convenience to use the space of their rooms. Most of the building designers like to prepare open-plan space, soundproof effect, and easy to operate. The solution of the designers need is the movable partition.
Bunge movable partition products as follow:
1.Ordinary Series:65MM,85MM;
2.High Sound-Proof Series:85MM,100MM;
3.Super High Series: Steel Track System
4.Glass Series:65MM & 85MM Aluminum Frame.

Function Room Divider Stackable Folding Partition Panel for Movie Room

5.Customer Photos
We have clients from all over the world, they are satisfied with our soundproof movable partition walls.When they came to our factory, they all surprised at our environment and our technology.There are a big movable wall show room in our factory, with different finish samples. Like glass partition, melamine partition, leather partition, fabric partition etc.
6.Why use the movable partition wall?
Folding the partition wall can separate the space speedily and conveniently. There is a top hung system without the need for a floor track.
Conference room soundproof wall partition is made from high density aluminum frame, specially made rubber, excellent sound insulation cotton and finish surface, etc.
Around the panel, there is sound insulation rubber, it can help to insulate the sound entering. Soundproof movable partition wall is hanging on the aluminum track, assembled with muti direction wheels.

Function Room Divider Stackable Folding Partition Panel for Movie Room

Do not consider more, welcome to inquiry to us.
